Cranks Spider for Road Chainrings

The original ALUGEAR design

TECHNICAL SPECIFICATIONS

• Intended to use:  Road, Gravel

• Crank interface:  8 bolt Direct Mount

• Chainrings interface:  110 BCD Shimano Asymmetric Road

• Weight:  59g

• Material: aluminum 7075-T6

• Made: CNC milling

• Surface coating: anodizing

• Colors: black, silver, red, blue, green, orange, gold, purple, steel, mocha

COMPATIBILITY

Spider ALUGEAR for 8-Bolt Direct Mount Cranks. It provides a secure and precise connection between the crank arm and the chainring, ensuring maximum power transfer and drivetrain stiffness

• The ALUGEAR Spider is designed for use with 8-bolt direct mount cranks. Its primary use is with Road Cranks that have a removable direct mount 8-bolts chainring or spider, such as ALUGEAR Vega Cranks; SRAM Red, Force, Rival XPLR, Apex 1 cranks; and any other cranks with spider/chainring direct mount 8-bolt

• The ALUGEAR Spider is compatible with ALUGEAR 1X and 2X chainrings featuring the 110 BCD 4-bolt Shimano Asymmetric Road, as well as with Shimano Ultegra FC-R8100 chainrings

INFORMATION

ALUGEAR Spider is engineered from high-grade aluminum and precision CNC-machined

The Spider features pocketing that optimizes the balance between maximum stiffness and minimal weight, delivering efficient power transfer without compromising strength or reliability, and perfect alignment for modern high-performance drivetrains

Quality Manufacturing - proudly made in Poland

RECOMMENDATIONS

The ALUGEAR Spider is mounted to the crank arm using 8 bolts

The recommended tightening torque for the spider mounting bolts is 4 Nm. Tool holder: T20 Torx

Mounting ALUGEAR chainrings:

1X and 2X chainrings can be installed using the ALUGEAR Cover and ALUGEAR Bolts and Nuts

The recommended tightening torque for these bolts is not more than 10 Nm

Use only original ALUGEAR bolts, as bolts from other manufacturers may differ in length or thread pitch, which could lead to component damage

Mounting Shimano chainrings:

Chainrings can be mounted using ALUGEAR bolts or Shimano bolts

In this case, the bolts thread directly into the Shimano chainring

The recommended tightening torque is not more than 10 Nm

Use a torque wrench for precise tightening

INSTALLATION INSTRUCTION

The Spider installation with 2X ALUGEAR chainrings

The Spider installation with 1X ALUGEAR chainring

Delivery includes: 1 pcs Spider
